Vertiv(Knürr) PowerIT Rack PDU, Switched (Unit Level), EC, 0U, input IEC 60309 230V 16A, locking outlets (10)C13 (2)C19

* Auftragsbezogen, nicht Stornierbar*, Product Specification and Options System Features Monitoring Input power monitoring with Outlet switching. Environmental monitoring via optional remote sensors. Daisy chain Ethernet connectivity. Local high visibility display. Input Monitoring Phase (A) Monitoring (kWh, W, VA, PF, V, A)

Power Measurements Compliant with ANSI C12.1 and IEC 62053-21 at 1% Accuracy Class Requirements Remote Power Management Individual Outlet Switching with Optional User Defined Time Delays and Sequential Power-up Quantity Of Inputs 1 Voltage 200-240V Current 16A VA per Input (Load Capacity) 3.6kW (230V) Frequency 50/60Hz Over Current Protection None Switch No LCD Touchscreen Display / Auto Oriented Yes Indicators - LED(s) 12 Power Cable Wire Gauge 2.5mm² H07RN-F Power Cable Length 10ft / 3m Power Entry Location Bottom Front Plug Type IEC60309 1P + N + E, 16A, 250V, Splashproof IP44 Combined Total Receptacle/Socket Quantity 12 Receptacle/Socket Type #1 U-Lock IEC C13 - Quantity on Face 10 - U-Lock Color ID 1 Circuit = Orange - Style Individual - Voltage per Receptacle/Socket 230V Receptacle/Socket Type #2 U-Lock IEC C19 - Quantity on Face 2 - U-Lock Color ID 1 Circuit = Orange - Style Individual - Voltage per Receptacle/Socket 230V Network Connection Dual 10/100/1000Mbps Ethernet Protocols Supported DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+, Modbus TCP Data Access Formats CSV datalog, JSON API, JSON datalog USB Support Yes IP Reset Button Yes Hard Reboot Button Yes Serial Connection RS232 via RJ45 Remote Sensor RJ Connection Jacks 1 (Supports up to 16 Sensors) Maximum Operating Temperature 60C / 140F Heavy Steel - Powder Coat Finish Black Configuration Zero U 7938 Vertical Mounting Bracket Kit Yes Toolless Mounting Hardware - Center to Center Spacing 622mm Product Warranty 5-year limited warranty Certification/Agency Approvals CE Marked Certification/Agency Approvals UKCA Marked Certification/Agency Approvals Complies with IEC 62368-1 (DOC Available) Certification/Agency Approvals Complies with EN 55032 and EN 55035 Certification/Agency Approvals RoHS Compliant Certification/Agency Approvals RCM Mark (EMC Only) Certification/Agency Approvals China RoHS Certification/Agency Approvals C? Mark Chassis Dimensions (LxWxD) 34in x 2in x 2.6in / 864mm x 51mm x 66mm Doghouse (D) 1.4in / 36mm Shipped Weight 18lbs (8.16kg)
